John Deere VacuMeter™ 2109, 2111, 2113, 2115, 2117, 2122, 2126, 2130 and 2134 Planters (South America) Service Repair Manual (TM809319)

John Deere VacuMeter™ 2109, 2111, 2113, 2115, 2117, 2122, 2126, 2130 and 2134 Planters (South America) Service Repair Manual (TM809319)

Illustrated factory Repair Manual for John Deere VacuMeter™ Planters Models 2109, 2111, 2113, 2115, 2117, 2122, 2126, 2130 and 2134.

This manual will assist you in assembling, disassembling, and repairing for your planter.
You can use a Windows, Mac, or Android device to view this manual. You only need to have a PDF reader installed.

Covered Models (South America):
   VacuMeter™ 2109 (SN: 140100-)
   VacuMeter™ 2111 (SN: 140100-)
   VacuMeter™ 2113 (SN: 140100-)
   VacuMeter™ 2115 (SN: 140100-)
   VacuMeter™ 2117 (SN: 140100-)
   VacuMeter™ 2122 (SN: 140100-)
   VacuMeter™ 2126 (SN: 140100-)
   VacuMeter™ 2130 (SN: 140100-)
   VacuMeter™ 2134 (SN: 140100-)

Table of Contents:
   Introduction
      Foreword
   Safety
      Safety
   General information
      Adjustments, Checks, and General Service
      References for Technical Information
   Frame, Hitch, Wheel Support and Row Markers
      Repair and Welding
      Chassis
      Single Hitch
      DualFlexPro Hitch
      Wheel Supports
      Wheel Hub
      Single Row Marker
      Bi-Fold Row Markers
      Monitoring Systems
   Mechanical Transmission
      Transmission Shafts
      Clutch and Drive
   Variable Rate Drive (VRD)
      Transmission Shafts
      Transmission
      Monitoring Systems
   Electrical System
      Connectors
      Wire Harnesses
      Electric Components
   Electronic Control Units
      General information
      Removing and Installing Components
   Fertilizer Units
      Fertilizer Hoppers
      Fertilizer Meters
      Fertilizer Metering Disks
      Fertilizer Furrow Opener Hoe
      Opener Disks
   Planting Units
      Row Units
      MaxEmerge 5 Seed Meters
      Closing Wheels
      Gauge Wheels
      Seed Furrow Opener Disks
      Planting Unit Pressure Assembly
      Row Cleaner
      Monitoring Systems
   Central Commodity System (CCS)
      CCS Pressure System
      CCS Turbine
      CCS Hopper
      Seed Delivery Manifold
      Delivery Hoses
      Monitoring Systems
   Hydraulic System
      Engines
      Valves
      Oil Cooler
      Hydraulic Cylinders
   Vacuum System
      Vacuum System
      Vacuum Turbine
   Dealer-Fabricated Tools
      Dealer Fabricated Tools

Format: PDF, 321 pages
Language: English
Publication Date: 12 Oct 2021
