John Deere 135 Draper Platforms Service Technical Manual (TM1280)

John Deere 135 Draper Platforms Service Technical Manual (TM1280)

Illustrated factory Technical Manual for John Deere Draper Platforms Models 135.

This manual will assist you in diagnosing, and repairing for your draper platform.
You can use a Windows, Mac, or Android device to view this manual. You only need to have a PDF reader installed.

Covered Models:
   135
Table of Contents:
   Draper Platform
   Introduction
   GENERAL
      Safety
      Specifications and Torques
      Description
      Lubrication
   POWER TRAIN
      Reel
      PTO Hookup
      Gear Case
      Right-Hand and Left-Hand Cross Shaft
      Canvas
      35 and 65 Conditioner
   HYDRAULIC SYSTEM
      Diagnosis and Tests
      Control Valve
      Reel Drive Motor
      Reel Lift Cylinders
      Reel Drive Pump
      Reservoir
   CUTTING COMPONENTS
      Knife Drive Case
      Cutterbars
      Knives
   SPECIAL TOOLS
      Fabricated Tools
      Special Tools

Format: PDF, 176 pages
Language: English
Publication Date: 01 Jul 1982
